| General ordering data | |
| Type | CP SNT 25W 5V 5A |
| Order No. | 8754960000 |
| Version | Power supply, switch-mode power supply unit, 5 V |
| GTIN (EAN) | 4032248426119 |
| Qty. | 1 pc(s). |
| Availability | Stock article |
| Dimensions and weights | |
| Width | 70 mm |
| Width (inches) | 2.756 inch |
| Height | 90.5 mm |
| Height (inches) | 3.563 inch |
| Depth | 62.5 mm |
| Depth (inches) | 2.461 inch |
| Weight | 0.2 kg |
| Net weight | 346 g |
| Temperatures | |
| Humidity at operating temperature | 5...95% (indoor), Tu = 40°C, no condensation |
| Operating temperature, max. | 70 °C (Derating ab 55 °C) |
| Operating temperature, min. | -10 °C |
| Storage temperature, max. | 85 °C |
| Storage temperature, min. | -20 °C |
| Operating temperature | -10 °C...70 °C (Derating ab 55 °C) |
| Storage temperature | -20 °C...85 °C |
| Input | |
| Connection system | Screw connection |
| DC input voltage range | 80...370 V DC |
| Input current | 500 mA at rated load @ 230 V AC |
| Input current at 115 Vac | 500 mA |
| Input current at 230 Vac | 500 mA |
| Input frequency | 50/ 60 Hz |
| Input fuse | Fusible link 2.5 A (T) / 250 V |
| Input voltage (voltage mode input) | 85...264 V AC / 110...370 V DC |
| Inrush Current Limitation | Yes |
| Wire connection method | Screw connection |
| output | |
| Control at 10...100% load | 1% |
| Mains failure bridge-over time | 11 ms @ 115 V AC / 50 ms @ 230 V AC |
| Max. capacitance at output | 10000 µF |
| Max. residual ripple | 120 mVSS |
| Output current | 5 A |
| Output power | 25 W |
| Output voltage | 5 V |
| Output voltage | 4...8 V (adjustable via potentiometer) |
| Output voltage type | DC |
| Overload protection | 105 %...150 % Iconst of max. output load; automatic reset |
| Parallel connection option | Max. 3 devices (rated voltages are to be calibrated at ±20 mV) |
| Surge protection | Varistor |
| Wire connection method | Screw connection |
| General data | |
| Building Width | 62.5 mm |
| Building height | 90.5 mm |
| Degree of efficiency at max. load | 70% |
| EMC standards | EN 55011, EN 55022, EN 61000-3-2,-3, EN 61000-6-2,-3,-4 |
| Installation advice | For side-by-side mounting, clearance: above/below > 30 mm |
| MTBF | > 500,000 h acc. to IEC 1709 (SN29500 |
| Mounting position, installation notice | horizontally, on terminal rail TS 35 |
| Operating temperature | -10 °C...70 °C (Derating ab 55 °C) |
| Protection degree | IP20 |
| Short-circuit protection | Yes |
| Standards | DIN EN 50178 (PELV), DIN EN 60950 (SELV) |
| Status indication | Green LED |
| Weight | 0.2 kg |
| Systemdaten | |
| Output current | 5 A |
| Insulation coordination | |
| Humidity at operating temperature | 5...95% (indoor), Tu = 40°C, no condensation |
| electrical isolation, I/O rail | 4 kV |
| electrical isolation, input-earth | 1.5 kV |
| electrical isolation, input-output | 3 kV |
| electrical isolation, output-earth | 0.5 kV |
| Connection data (input) | |
| Connection system | Screw connection |
| Signalling | |
| Status indication | Green LED |
| Основные | |
|---|---|
| Состояние | Новое |
- Цена: Цену уточняйте
