| General ordering data | |
| Type | CP E SNT 100W 12V 8.5A |
| Order No. | 1165830000 |
| Version | Power supply, switch-mode power supply unit |
| GTIN (EAN) | 4032248956685 |
| Qty. | 1 pc(s). |
| Availability | Delivery date on request |
| Dimensions and weights | |
| Width | 97.5 mm |
| Width (inches) | 3.839 inch |
| Height | 40 mm |
| Height (inches) | 1.575 inch |
| Depth | 164 mm |
| Depth (inches) | 6.457 inch |
| Net weight | 548 g |
| Temperatures | |
| Storage temperature, max. | 85 °C |
| Storage temperature, min. | -20 °C |
| Ambient temperature | -20°C…70°C (>50°C derating,refer derated curve); 70% rated load@70°C |
| Storage temperature | -20 °C...85 °C |
| Input | |
| AC current consumption | 1.5 A @ 230 V AC / 3 A @ 120 V AC |
| AC input voltage range | 88…132 V AC / 176…264 V AC optional |
| Connection system | Screw connection |
| DC input voltage range | 250...370 V DC |
| Frequency range AC | 47...63 Hz |
| Input fuse (internal) | yes / max. 20A |
| Rated input voltage | 100...240 V AC (wide-range input) |
| Recommended back-up fuse | 4 A at 230 V AC, characteristic curve C |
| output | |
| Mains failure bridge-over time | 20 ms |
| Output current | 8.5 A@12 V DC |
| Output power | 100 W |
| Output voltage | ± 10% nominal output voltage tolerance, adjustable with potentiometer |
| Overload protection | 120~150% Ikonst. of max. output power, automatic restart |
| Parallel connection option | Recommended with diode module |
| Rated output voltage | 12 V DC |
| Residual ripple, breaking spikes | < 100 mVPP |
| Surge protection | 13.5...16.2 V @ 12 V DC |
| General data | |
| AC failure bridging time @ INom | min. 20 ms |
| Ambient temperature | -20°C…70°C (>50°C derating,refer derated curve); 70% rated load@70°C |
| Degree of efficiency | 81 % @ 12 V DC |
| EMC standards | EN 55011, EN 55022, EN 55024, EN 61000-6 /-2, -3 |
| Indication | Operation, green LED |
| Max. perm. air humidity (operational) | 5 %…95 % RH |
| Mounting position, installation notice | Panel mount, screw fix |
| Protection degree | IP20 |
| Short-circuit protection | Yes |
| Standards | EN 60950 |
| Systemdaten | |
| Output current | 8.5 A@12 V DC |
| EMC / shock / vibration | |
| Noise emission acc. to EN55022 | Class A |
| Insulation coordination | |
| electrical isolation, input-earth | 2 kV |
| electrical isolation, input-output | 3 kV |
| electrical isolation, output-earth | 0.5 kV |
| Connection data (input) | |
| Connection system | Screw connection |
| Основные | |
|---|---|
| Состояние | Новое |
- Цена: Цену уточняйте
